product performance
Improve the traceability of pressure changes. Achieve finer coating. Improve the coating stability and maintainability of low viscosity liquid agent.
| Parameter specification | ||
| Dispensing method | Air compression mode | |
| Control mode | Microcomputer electronic/pneumatic control type | |
| Spitting mode | Timed mode/manual mode | |
| Discharge pressure/time setting range | 0.030~0.500 MPa/0.001~9999.999 s | |
| Vacuum pressure setting range | _0.020~0MPa | |
| output signal | Preparation, dispensing completed, dispensing in progress, dispensing cycle, solenoid valve alarm, , residual power on. | |
| Power supply and frequency | AC100-240V 50/60Hz | |
| Air supply pressure | g, dispensing counter, sto Automatic correction difference,drip pwatch, Japanese-English vacuum pressure error, | |
| outline dimension | W300xD300xH100 mm | |
| Heavy weight | 5.8 KG | |
